- Brand
- MikroTik
- Model
- Chateau 5G R17 ax
- Product code
- S53UG+5HaxD2HaxD-TC&RG650E-EU
- Cellular modem
- RG650E-EU
- CPU
- Quad-Core IPQ-6010, 864-1800 MHz
- CPU architecture
- ARM 64bit
- CPU core count
- 4
- RAM
- 1 GB
- Storage
- 128 MB NAND
- Operating system
- RouterOS v7, License level 4
- Ethernet ports
- 4 x 10/100/1000 Ethernet, 1 x 2.5G Ethernet
- SIM support
- 1 x Micro SIM, eSIM
- USB ports
- 1 x USB 3.0 Type-A
- 2.4 GHz Wi-Fi
- 802.11b/g/n/ax, Wi-Fi 6, 2 chains, up to 574 Mbit/s, 3 dBi antenna gain
- 5 GHz Wi-Fi
- 802.11a/n/ac/ax, Wi-Fi 6, 2 chains, up to 1200 Mbit/s, 6 dBi antenna gain
- Wireless chipsets
- QCN-5022 (2.4 GHz), QCN-5052 (5 GHz)
- LTE category
- Category 20; up to 2.0 Gbps downlink and 211 Mbps uplink
- LTE FDD bands
- 1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 28 (700 MHz), 32 (1500 MHz)
- LTE TDD bands
- 38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz), 42 (3500 MHz), 43 (3700 MHz)
- 5G SA category
- Up to 7.01 Gbps downlink and 1.25 Gbps uplink
- 5G NSA category
- Up to 5.47 Gbps downlink and 730 Mbps uplink
- 5G SA FDD bands
- 1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 26 (850 MHz), 28 (700 MHz), 67 (700 MHz), 75 (1500 MHz), 76 (1500 MHz)
- 5G SA TDD bands
- 38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz), 77 (3700 MHz), 78 (3500 MHz)
- 5G NSA FDD bands
- 1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 26 (850 MHz), 28 (700 MHz), 67 (700 MHz), 75 (1500 MHz), 76 (1500 MHz)
- 5G NSA TDD bands
- 38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz), 77 (3700 MHz), 78 (3500 MHz)
- 5G MIMO
- 4x4 downlink; 1x1 uplink (2x2 uplink in 5G SA)
- 3G category
- R8; up to 42.2 Mbps downlink and 5.76 Mbps uplink
- 3G bands
- 1 (2100 MHz), 5 (850 MHz), 8 (900 MHz)
- Dimensions
- 240 x 156 x 44 mm
- Operating temperature
- -40°C to +70°C
- Power input
- 12-28 V DC, DC jack
- Power adapter
- 24 V, 1.2 A
- Maximum power consumption
- 27 W
- Maximum power consumption without attachments
- 18 W
- Enclosure rating
- IP20
- Certifications
- CE, EAC, RoHS
