- Product code
- D53G-5HacD2HnD-TC&EG06-A
- Architecture
- ARM 32bit
- CPU
- IPQ-4019
- CPU core count
- 4
- CPU nominal frequency
- 488-896 (auto) MHz
- CPU threads count
- 4
- Switch chip model
- IPQ-4019
- Dimensions
- 240 x 156 x 44 mm
- RouterOS license
- 4
- Operating system
- RouterOS v7
- RAM
- 256 MB
- Storage size
- 16 MB
- Storage type
- FLASH
- MTBF
- Approximately 200'000 hours at 25°C
- Tested ambient temperature
- -40°C to 70°C
- DC inputs
- 1 (DC jack)
- DC jack input voltage
- 12-28 V
- Maximum power consumption
- 19 W
- Maximum power consumption without attachments
- 14.3 W
- Cooling type
- Passive
- 3G category
- R8 (42.2 Mbps downlink, 5.76 Mbps uplink)
- 3G bands
- Band 2 (1900 MHz), Band 4 (1700 MHz), Band 5 (850 MHz)
- LTE category
- Category 6 (300 Mbit/s downlink, 50 Mbit/s uplink)
- LTE FDD bands
- Band 2 (1900 MHz), Band 4 (1700 MHz), Band 5 (850 MHz), Band 7 (2600 MHz), Band 12 (700 MHz), Band 13 (700 MHz), Band 25 (1900 MHz), Band 26 (850 MHz), Band 29 (700 MHz), Band 30 (2300 MHz), Band 66 (1700 MHz)
- TAC
- 01619900
- 2.4 GHz maximum data rate
- 300 Mbit/s
- 2.4 GHz wireless chains
- 2
- 2.4 GHz wireless standards
- 802.11b/g/n
- 2.4 GHz antenna gain
- 3 dBi
- 2.4 GHz wireless chip
- IPQ-4019
- 2.4 GHz Wi-Fi generation
- Wi-Fi 4
- 5 GHz maximum data rate
- 867 Mbit/s
- 5 GHz wireless chains
- 2
- 5 GHz wireless standards
- 802.11a/n/ac
- 5 GHz antenna gain
- 5.5 dBi
- 5 GHz wireless chip
- IPQ-4019
- 5 GHz Wi-Fi generation
- Wi-Fi 5
- Ethernet ports
- 5 x 10/100/1000 Mbps
- SIM slots
- 1 modem slot (Micro SIM)
- USB ports
- 1
- USB power reset
- Yes
- USB slot type
- USB Type-A
- Maximum USB current
- 1 A
- Mode button
- Yes
- Certifications
- CE, FCC, EAC, ROHS
- Included accessories
- UTP Flat Cable (1.5m); 24V 1.2A power adapter (US)
- 2.4 GHz transmit power / receive sensitivity
- 1 Mbit/s: 25 dBm / -100 dBm; 11 Mbit/s: 25 dBm / -94 dBm; 6 Mbit/s: 26 dBm / -96 dBm; 54 Mbit/s: 23 dBm / -78 dBm; MCS0: 26 dBm / -96 dBm; MCS7: 22 dBm / -73 dBm
- 5 GHz transmit power / receive sensitivity
- 6 Mbit/s: 26 dBm / -96 dBm; 54 Mbit/s: 22 dBm / -80 dBm; MCS0: 26 dBm / -96 dBm; MCS7: 21 dBm / -75 dBm; MCS9: 19 dBm / -70 dBm
- Wireless antennas
- 2 integrated LTE antennas, 2x2 MIMO; 2 external LTE antenna connectors (SMA female)
