مودم و روتر فضای باز MikroTik SXT LTE7 kit

مشخصات

Brand

MikroTik

Model

SXT LTE7 kit

Product code

SXTR&R11e-LTE7

LTE modem

R11e-LTE7

CPU

QCA9531

CPU architecture

MIPSBE

CPU core count

1

CPU nominal frequency

650 MHz

Switch chip

QCA9531

Operating system

RouterOS v7

RouterOS license level

3

RAM capacity

64 MB

RAM type

DDR2

Storage capacity

16 MB

Storage type

Flash

MTBF

Approximately 200,000 hours at 25°C

Operating temperature

-40°C to 60°C

Dimensions

140 × 140 × 56 mm

Ingress protection

IP54

LTE category

Category 7

LTE maximum data rate

Downlink: 300 Mbps; uplink: 100 Mbps

LTE downlink MIMO

2 × 2

LTE uplink MIMO

1 × 1

LTE FDD bands

1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 28 (700 MHz), 32 (1500 MHz)

LTE TDD bands

38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz)

3G category

R8; downlink: 42.2 Mbps; uplink: 5.76 Mbps

3G bands

1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 8 (900 MHz)

Carrier aggregation

Supported

Ethernet ports

2 × 10/100 Mbps

SIM slots

2 × Micro-SIM

Mini PCIe slots

1

DC input

1 × PoE-IN

PoE input voltage

12–57 V

PoE input standard

IEEE 802.3af/at

PoE output port

Ether2

PoE output type

Passive PoE, up to 57 V

Maximum power consumption

24 W

Maximum power consumption without attachments

7 W

Cooling

Passive

Included power adapter

24 V, 1.2 A

Certifications

CE, EAC, RoHS

Included accessories

24 V 1.2 A power adapter, Gigabit PoE injector, metal ring, pole mounting bracket, elastic thermal pad
