- Brand
- MikroTik
- Model
- hAP ac
- Product code
- RB962UiGS-5HacT2HnT (International)
- Device type
- Dual-band wireless router and access point
- Architecture
- MIPSBE
- CPU
- QCA9558
- CPU core count
- 1
- CPU nominal frequency
- 720 MHz
- Switch chip model
- QCA8337
- Operating system
- RouterOS v7
- RouterOS license
- 4
- RAM
- 128 MB
- Storage capacity
- 16 MB
- Storage type
- FLASH
- Dimensions
- 114 x 137 x 29 mm
- MTBF
- Approximately 200,000 hours at 25°C
- Tested ambient temperature
- -40°C to 70°C
- Wireless bands
- 2.4 GHz and 5 GHz (concurrent)
- 2.4 GHz wireless standards
- 802.11b/g/n
- 2.4 GHz maximum data rate
- 450 Mbit/s
- 2.4 GHz number of chains
- 3
- 2.4 GHz antenna gain
- 2.5 dBi
- 2.4 GHz wireless chip
- QCA9558
- 2.4 GHz Wi-Fi generation
- Wi-Fi 4
- 5 GHz wireless standards
- 802.11a/n/ac
- 5 GHz maximum data rate
- 1300 Mbit/s
- 5 GHz number of chains
- 3
- 5 GHz antenna gain
- 2 dBi
- 5 GHz wireless chip
- QCA9880
- 5 GHz Wi-Fi generation
- Wi-Fi 5
- Wi-Fi class
- AC1750
- 10/100/1000 Ethernet ports
- 5
- SFP ports
- 1
- USB ports
- 1
- USB slot type
- USB Type-A
- Maximum USB current
- 1 A
- USB power reset
- Yes
- DC inputs
- 2 (DC jack and PoE-IN)
- DC jack input voltage
- 11–57 V
- PoE-IN type
- Passive PoE
- PoE-IN voltage
- 11–57 V
- PoE-OUT port
- Ether5
- PoE-OUT type
- Passive PoE
- PoE-OUT current limit (low voltage)
- 700 mA
- PoE-OUT current limit (high voltage)
- 350 mA
- Maximum total PoE-OUT current
- 700 mA
- Maximum power consumption
- 17 W
- Cooling
- Passive
- Ingress protection rating
- IP20
- Certifications
- CE, FCC, IC, EAC, ROHS
- PCB temperature monitor
- Yes
- Voltage monitor
- Yes
- Beeper
- Yes
- Included power adapter
- 24 V, 1.2 A
