رادیو وایرلس MikroTik RB912UAG-5HPnD

مشخصات

Product code

RB912UAG-5HPnD

Architecture

MIPSBE

CPU

AR9342

CPU core count

1

CPU nominal frequency

600 MHz

Dimensions

105 × 105 mm

RouterOS license

4

Operating system

RouterOS

RAM

64 MB

Storage capacity

128 MB NAND

MTBF

Approximately 100,000 hours at 25°C

Tested ambient temperature

−40°C to 70°C

DC inputs

2 (DC jack, PoE-IN)

DC jack input voltage

8–30 V

Maximum power consumption

12 W

PoE input

Passive PoE

PoE input voltage

8–30 V

Cooling

Passive

5 GHz maximum data rate

300 Mbit/s

5 GHz wireless chains

2

5 GHz wireless standards

802.11a/n

5 GHz wireless chip

AR9342

Wi-Fi generation

Wi-Fi 4

Gigabit Ethernet ports

1 × 10/100/1000 Ethernet

SIM slots

1 × Mini SIM (modem)

Mini PCI-e slots

1

USB ports

1

USB connector type

USB Type-A

Maximum USB current

1 A

USB power reset

Yes

PCB temperature monitor

Yes

Voltage monitor

Yes

Beeper

Yes

ESD protection

16 kV on Ethernet and MMCX ports

Certifications

CE, FCC, IC, EAC, RoHS

IP rating

IP00

5 GHz transmit power

6 Mbit/s: 30 dBm; 54 Mbit/s: 27 dBm; MCS0: 30 dBm; MCS7: 26 dBm

5 GHz receive sensitivity

6 Mbit/s: −96 dBm; 54 Mbit/s: −78 dBm; MCS0: −96 dBm; MCS7: −75 dBm

Operating frequency range (international version)

5150–5875 MHz; subject to country regulations
