مشخصات

Product code

RBGrooveA-52HPn

Architecture

MIPSBE

CPU

AR9342

CPU core count

1

CPU nominal frequency

600 MHz

Dimensions

177 × 44 × 44 mm

Weight

193 g

RouterOS license

4

Operating system

RouterOS

RAM size

64 MB

Storage size

16 MB

Storage type

FLASH

MTBF

Approximately 100,000 hours at 25°C

Tested ambient temperature

-40°C to 70°C

DC inputs

1 (PoE-IN)

Maximum power consumption

6 W

PoE input type

Passive PoE

PoE input voltage

9–30 V

Cooling type

Passive

Wireless bands

2.4 GHz / 5 GHz (software selectable)

Maximum wireless data rate

150 Mbit/s

Wireless chains

1

Wireless standards

802.11b/g/n, 802.11a/n

Antenna gain

6 dBi (2.4 GHz); included omni antenna: 6 dBi (2.4 GHz), 8 dBi (5 GHz)

Wireless chip model

AR9342

Wi-Fi generation

Wi-Fi 4

Ethernet ports

1 × 10/100 Ethernet

Connector

N-male

International frequency range

2412–2484 MHz; 5150–5875 MHz (country regulations may limit specific frequencies)

PCB temperature monitor

Yes

Voltage monitor

Yes

Beeper

Yes

Certifications

CE, FCC, IC, EAC, ROHS

Included items

Groove unit, mounting loops, PoE injector, power adapter, omni-directional antenna (6 dBi at 2.4 GHz; 8 dBi at 5 GHz)

Wireless transmit power / receive sensitivity (2.4 GHz)

1 Mbit/s: 27 dBm / -97 dBm; 11 Mbit/s: 27 dBm / -91 dBm; 6 Mbit/s: 27 dBm / -93 dBm; 54 Mbit/s: 24 dBm / -75 dBm; MCS0: 27 dBm / -93 dBm; MCS7: 23 dBm / -70 dBm

Wireless transmit power / receive sensitivity (5 GHz)

6 Mbit/s: 27 dBm / -93 dBm; 54 Mbit/s: 23 dBm / -75 dBm; MCS0: 26 dBm / -93 dBm; MCS7: 22 dBm / -70 dBm
