مشخصات

Brand

MikroTik

Product Model

hAP ac²

Product Code

RBD52G-5HacD2HnD-TC

Variant

International

Architecture

ARM 32-bit

CPU

IPQ-4018

CPU Core Count

4

CPU Thread Count

4

CPU Nominal Frequency

488–896 MHz (auto)

Switch Chip

IPQ-4018

Dimensions

34 × 119 × 98 mm

RouterOS License

4

Operating System

RouterOS

RAM

128 MB

Storage Capacity

16 MB

Storage Type

Flash

MTBF

Approximately 100,000 hours at 25°C

Tested Ambient Temperature

-40°C to 50°C

2.4 GHz Frequency Range

2412–2484 MHz; subject to local regulations

2.4 GHz Maximum Data Rate

300 Mbit/s

2.4 GHz Standards

802.11b/g/n

2.4 GHz Spatial Streams

2

2.4 GHz Antenna Gain

2.5 dBi

2.4 GHz Wi-Fi Generation

Wi-Fi 4

2.4 GHz Transmit Power

27 dBm at 1 Mbit/s, 11 Mbit/s, 6 Mbit/s and MCS0; 24 dBm at 54 Mbit/s; 23 dBm at MCS7

2.4 GHz Receive Sensitivity

-100 dBm at 1 Mbit/s; -94 dBm at 11 Mbit/s; -96 dBm at 6 Mbit/s and MCS0; -78 dBm at 54 Mbit/s; -73 dBm at MCS7

5 GHz Frequency Range

5150–5875 MHz; subject to local regulations

5 GHz Maximum Data Rate

867 Mbit/s

5 GHz Standards

802.11a/n/ac

5 GHz Spatial Streams

2

5 GHz Antenna Gain

2.5 dBi

5 GHz Wi-Fi Generation

Wi-Fi 5

5 GHz Transmit Power

26 dBm at 6 Mbit/s and MCS0; 22 dBm at 54 Mbit/s; 21 dBm at MCS7; 19 dBm at MCS9

5 GHz Receive Sensitivity

-96 dBm at 6 Mbit/s and MCS0; -80 dBm at 54 Mbit/s; -75 dBm at MCS7; -70 dBm at MCS9

Combined Wi-Fi Class

AC1200

Ethernet Ports

5 × 10/100/1000 Mbit/s

USB Ports

1

USB Connector

USB Type-A

Maximum USB Current

1 A

USB Power Reset

Yes

DC Inputs

2: DC jack and PoE-in

DC Jack Input Voltage

12–30 V

Passive PoE-in Voltage

18–28 V

PoE-in Type

Passive PoE

Maximum Power Consumption

21 W

Maximum Power Consumption Without Attachments

16 W

Cooling

Passive

IP Rating

IP20

Certifications

CE, FCC, IC, EAC, RoHS

Mode Button

Yes

Included Power Adapter

24 V, 0.8 A

Included Wall Mount Kit

K-47

Included Base

hAP case base
