- Brand
- MikroTik
- Model
- hAP ac lite
- Product code
- RB952Ui-5ac2nD
- Architecture
- MIPSBE
- CPU
- QCA9531
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
- Switch chip model
- QCA9531
- Dimensions
- 113 x 89 x 28mm
- RouterOS license
- 4
- Operating System
- RouterOS
- Size of RAM
- 64 MB
- Storage size
- 16 MB
- Storage type
- FLASH
- MTBF
- Approximately 100'000 hours at 25C
- Tested ambient temperature
- -30°C to 70°C
- Wireless 2.4 GHz Max data rate
- 300 Mbit/s
- Wireless 2.4 GHz Number of chains
- 2
- Wireless 2.4 GHz standards
- 802.11b/g/n
- Antenna gain dBi for 2.4 GHz
- 1.5
- Wireless 2.4 GHz chip model
- QCA9531
- Wireless 2.4 GHz generation
- Wi-Fi 4
- Wireless 5 GHz Max data rate
- 433 Mbit/s
- Wireless 5 GHz Number of chains
- 1
- Wireless 5 GHz standards
- 802.11a/n/ac
- Antenna gain dBi for 5 GHz
- 2
- Wireless 5 GHz chip model
- QCA9887
- Wireless 5 GHz generation
- Wi-Fi 5
- WiFi speed
- AC750
- 10/100 Ethernet ports
- 5
- Number of USB ports
- 1
- USB Power Reset
- Yes
- USB slot type
- USB type A
- Max USB current (A)
- 1
- Number of DC inputs
- 2 (DC jack, PoE-IN)
- DC jack input Voltage
- 10-28 V
- Max power consumption
- 20 W
- Max power consumption without attachments
- 8 W
- PoE in
- Passive PoE
- Cooling type
- Passive
- PoE in input Voltage
- 10-28 V
- PoE-out ports
- Ether5
- PoE out
- Passive PoE
- Low voltage PoE-Out current limit
- 500 mA
- Max total out (A)
- 500 mA
- Certification
- CE, FCC, IC, EAC, ROHS
- IP
- IP20
- Included parts
- 24V 1.2A power adapter
- Wireless 2.4 GHz 1MBit/s (Transmit / Receive Sensitivity)
- 22 dBm / -96 dBm
- Wireless 2.4 GHz 11MBit/s (Transmit / Receive Sensitivity)
- 22 dBm / -89 dBm
- Wireless 2.4 GHz 6MBit/s (Transmit / Receive Sensitivity)
- 20 dBm / -93 dBm
- Wireless 2.4 GHz 54MBit/s (Transmit / Receive Sensitivity)
- 18 dBm / -74 dBm
- Wireless 2.4 GHz MCS0 (Transmit / Receive Sensitivity)
- 20 dBm / -93 dBm
- Wireless 2.4 GHz MCS7 (Transmit / Receive Sensitivity)
- 16 dBm / -71 dBm
- Wireless 5 GHz 6MBit/s (Transmit / Receive Sensitivity)
- 23 dBm / -93 dBm
- Wireless 5 GHz 54MBit/s (Transmit / Receive Sensitivity)
- 20 dBm / -75 dBm
- Wireless 5 GHz MCS0 (Transmit / Receive Sensitivity)
- 23 dBm / -93 dBm
- Wireless 5 GHz MCS7 (Transmit / Receive Sensitivity)
- 19 dBm / -71 dBm
- Wireless 5 GHz MCS9 (Transmit / Receive Sensitivity)
- 16 dBm / -63 dBm
- Ethernet test: Bridging, none (fast path)
- 1518 byte: 40.6 kpps / 493.0 Mbps; 512 byte: 117.4 kpps / 480.9 Mbps; 64 byte: 217.0 kpps / 111.1 Mbps
- Ethernet test: Bridging, 25 bridge filter rules
- 1518 byte: 40.6 kpps / 493.0 Mbps; 512 byte: 70.1 kpps / 287.1 Mbps; 64 byte: 70.9 kpps / 36.3 Mbps
- Ethernet test: Routing, none (fast path)
- 1518 byte: 40.6 kpps / 493.0 Mbps; 512 byte: 117.4 kpps / 480.9 Mbps; 64 byte: 200.8 kpps / 102.8 Mbps
- Ethernet test: Routing, 25 simple queues
- 1518 byte: 40.6 kpps / 493.0 Mbps; 512 byte: 79.6 kpps / 326.0 Mbps; 64 byte: 90.8 kpps / 46.5 Mbps
- Ethernet test: Routing, 25 ip filter rules
- 1518 byte: 40.6 kpps / 493.0 Mbps; 512 byte: 42.2 kpps / 172.8 Mbps; 64 byte: 43.2 kpps / 22.1 Mbps
