- Brand
- MikroTik
- Product name
- cAP lite
- Product code
- RBcAPL-2nD
- Architecture
- MIPSBE
- CPU
- QCA9533
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
- Dimensions
- Wall case: 88 x 52 x 20 mm; Ceiling case: ⌀88 mm x 20 mm
- RouterOS license
- 4
- Operating System
- RouterOS
- Size of RAM
- 64 MB
- Storage size
- 16 MB
- Storage type
- FLASH
- MTBF
- Approximately 100'000 hours at 25°C
- Tested ambient temperature
- -40°C to 70°C
- Wireless 2.4 GHz Max data rate
- 300 Mbit/s
- Wireless 2.4 GHz Number of chains
- 2
- Wireless 2.4 GHz standards
- 802.11b/g/n
- Antenna gain dBi for 2.4 GHz
- 1.5
- Antenna beam width
- 360°
- Wireless 2.4 GHz chip model
- QCA9533
- Wireless 2.4 GHz generation
- Wi-Fi 4
- 10/100 Ethernet ports
- 1
- MicroUSB input Voltage
- 5 V
- Number of DC inputs
- 2 (PoE-IN, MicroUSB)
- Max power consumption
- 4 W
- PoE in
- 802.3af/at
- Cooling type
- Passive
- PoE in input Voltage
- 10-60 V
- Certification
- CE, FCC, IC, EAC, ROHS
- IP
- IP20
- Included parts
- 24V 0.2A power adapter; Fastening set; PoE injector; Wall case; Ceiling case
- 2.4 GHz 1MBit/s Tx / Rx sensitivity
- 22 dBm / -96 dBm
- 2.4 GHz 11MBit/s Tx / Rx sensitivity
- 22 dBm / -89 dBm
- 2.4 GHz 6MBit/s Tx / Rx sensitivity
- 20 dBm / -93 dBm
- 2.4 GHz 54MBit/s Tx / Rx sensitivity
- 18 dBm / -74 dBm
- 2.4 GHz MCS0 Tx / Rx sensitivity
- 20 dBm / -93 dBm
- 2.4 GHz MCS7 Tx / Rx sensitivity
- 16 dBm / -71 dBm
- Ethernet test: Bridging, none (fast path)
- 1518 byte: 8.1 kpps / 98.4 Mbps; 512 byte: 23.5 kpps / 96.3 Mbps; 64 byte: 173.6 kpps / 88.9 Mbps
- Ethernet test: Bridging, 25 bridge filter rules
- 1518 byte: 8.1 kpps / 98.4 Mbps; 512 byte: 23.5 kpps / 96.3 Mbps; 64 byte: 82.2 kpps / 42.1 Mbps
- Ethernet test: Routing, none (fast path)
- 1518 byte: 8.1 kpps / 98.4 Mbps; 512 byte: 23.5 kpps / 96.3 Mbps; 64 byte: 160.8 kpps / 82.3 Mbps
- Ethernet test: Routing, 25 simple queues
- 1518 byte: 8.1 kpps / 98.4 Mbps; 512 byte: 23.5 kpps / 96.3 Mbps; 64 byte: 118.7 kpps / 60.8 Mbps
- Ethernet test: Routing, 25 ip filter rules
- 1518 byte: 8.1 kpps / 98.4 Mbps; 512 byte: 23.5 kpps / 96.3 Mbps; 64 byte: 53.9 kpps / 27.6 Mbps
