مشخصات

Product code

L11UG-5HaxD

Architecture

ARM 32bit

CPU

IPQ-5010

CPU core count

2

CPU nominal frequency

800 MHz

CPU Threads count

2

RouterOS license

4

Operating System

RouterOS v7

Size of RAM

256 MB

Storage size

128 MB

Storage type

NAND

MTBF

Approximately 100'000 hours at 25C

Tested ambient temperature

-40°C to 70°C

Number of DC inputs

2 (DC jack, PoE-IN)

DC jack input Voltage

12-28 V

Max power consumption

15 W

Max power consumption without attachments

6 W

PoE in

Passive PoE

Cooling type

Passive

PoE in input Voltage

18-28 V

Wireless 5 GHz Max data rate

2400 Mbit/s

Wireless 5 GHz Number of chains

2

Wireless 5 GHz standards

802.11a/n/ac/ax

Wireless 5 GHz chip model

QCN-6102

Wireless 5 GHz generation

Wi-Fi 6

10/100/1000 Ethernet ports

1

Number of USB ports

1

USB Power Reset

Yes

USB slot type

USB type A

Max USB current (A)

1.5

PCB temperature monitor

Yes

Voltage Monitor

Yes

Beeper

Yes

Certification

CE, FCC, IC, EAC, ROHS

IP

00

Wireless 5 GHz transmit / receive sensitivity

6MBit/s: 28 dBm / -96 dBm; 54MBit/s: 26 dBm / -80 dBm; MCS0: 28 dBm / -96 dBm; MCS7: 25 dBm / -75 dBm; MCS9: 23 dBm / -70 dBm; MCS11: 20 dBm / -67 dBm
