مشخصات

Brand

MikroTik

Model

LHG 5

Product code

RBLHG-5nD

Architecture

MIPSBE

CPU

AR9344

CPU core count

1

CPU nominal frequency

600 MHz

RAM size

64 MB

Storage size

16 MB

Storage type

FLASH

Operating system

RouterOS

RouterOS license

Level 3

Device dimensions

Ø 391 × 222 mm

Package dimensions

450 × 450 × 145 mm

MTBF

Approximately 100,000 hours at 25°C

Tested ambient temperature

-40°C to 70°C

Number of DC inputs

1 (PoE-IN)

Max power consumption

6 W

PoE in

Passive PoE

PoE in input voltage

11–30 V

Cooling type

Passive

Wireless 5 GHz max data rate

300 Mbit/s

Wireless 5 GHz number of chains

2

Wireless 5 GHz standards

802.11a/n

Antenna gain for 5 GHz

24.5 dBi

Wireless 5 GHz chip model

AR9344

Wireless 5 GHz generation

Wi-Fi 4

International version frequency range

5150–5875 MHz; may be limited by country regulations

US version frequency range

5170–5250 MHz and 5725–5835 MHz; factory locked and cannot be removed

10/100 Ethernet ports

1

IP rating

IP54

Certifications

CE, FCC, IC, EAC, ROHS

Wireless transmit power and receive sensitivity

6 Mbit/s: 25 dBm transmit, -96 dBm receive sensitivity; 54 Mbit/s: 20 dBm, -80 dBm; MCS0: 25 dBm, -96 dBm; MCS7: 19 dBm, -75 dBm

Included parts

K-LHG kit, 24 V 0.38 A power adapter, PoE injector, two metal rings
