مشخصات

Brand

MikroTik

Model

CRS520-4XS-16XQ-RM

Product code

CRS520-4XS-16XQ-RM

Product type

Rackmount enterprise switch

CPU architecture

ARM 64-bit

CPU model

AL52400

CPU cores

4

CPU threads

4

CPU nominal frequency

2 GHz

Switch chip

98CX8410

RAM

4 GB DDR4

Storage

128 MB NAND

Operating system

RouterOS v7

RouterOS license

Level 5

QSFP28 ports

16 × 100G

QSFP28 supported speeds

4 × 1G / 4 × 2.5G / 4 × 10G / 4 × 25G / 1 × 40G / 2 × 50G / 1 × 100G, depending on module

SFP28 ports

4 × 25G

SFP28 supported speeds

1G / 2.5G / 10G / 25G, depending on module

Ethernet ports

2 × 10M/100M/1G/10G

Serial console

RJ45

AC inputs

2

Power supply slots

2

AC input voltage

100–240 V

AC input frequency

50–60 Hz

Maximum power consumption

150 W (220 W with both PSUs)

Maximum power consumption without attachments

123 W

Cooling

4 hot-swappable fans

Power supplies

2 hot-swappable AC power supplies

Dimensions

443 × 367 × 44 mm

Tested ambient temperature

−20 °C to +50 °C

MTBF

Approximately 200,000 hours at 25 °C

Ingress protection rating

IP20

Certifications

CE, EAC, RoHS

Hardware monitoring

CPU temperature, PCB temperature, voltage

Included accessories

2 IEC power cords, rackmount ears, rear support ears, cable management brackets, K-82 fastening set
