سوئیچ MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM

مشخصات

Product code

CRS418-8P-8G-2S+5axQ2axQ-RM

Brand

MikroTik

Architecture

ARM 64bit

CPU

IPQ-8072A, 4 cores, 4 threads, 2208 MHz nominal frequency

Switch chip

98DX226S

Operating system

RouterOS v7; RouterOS license level 5

RAM

1 GB

Storage

128 MB NAND

Ethernet ports

17 × 10/100/1000 Mbps

PoE-out Ethernet ports

8 × Gigabit Ethernet (Ether9–Ether16)

PoE-out standards

802.3af/at; 24 V passive PoE output

Total PoE output power

150 W

SFP+ ports

2 × 10G SFP+

Wireless

Dual-band Wi-Fi 6, 4×4 MIMO

2.4 GHz wireless

Up to 1148 Mbit/s; 4 chains; 802.11b/g/n/ax; QCN-5024; 5 dBi antenna gain

5 GHz wireless

Up to 2400 Mbit/s; 4 chains; 802.11a/n/ac/ax; QCN-5054; 6 dBi antenna gain

USB

1 × USB 3.0 Type-A; maximum current 1 A; USB power reset

Serial console

RJ45

Power inputs

2 × AC inputs; 2 × PSU slots; 100–240 V AC, 50–60 Hz

Maximum power consumption

227 W; 43 W without attachments

Cooling

4 fans

Operating temperature

−20°C to 70°C

MTBF

Approximately 200,000 hours at 25°C

Monitoring

CPU temperature, PCB temperature, current and voltage monitors

Certifications

CE, FCC, IC, EAC, RoHS

Ingress protection

IP20
