- Product code
- CRS510-8XS-2XQ-IN
- Architecture
- MIPSBE
- CPU
- QCA9531
- CPU core count
- 1
- CPU nominal frequency
- 650 MHz
- Switch chip model
- 98DX4310
- RouterOS license
- 5
- Operating System
- RouterOS v7
- Size of RAM
- 128 MB
- Storage size
- 32 MB
- Storage type
- FLASH
- MTBF
- Approximately 200,000 hours at 25°C
- Tested ambient temperature
- -40°C to 70°C
- Number of AC inputs
- 2
- AC input range
- 100-240 V
- AC input frequency
- 47-63 Hz
- Number of DC inputs
- 3 (DC jack, PoE-IN, 2-pin terminal)
- DC jack input voltage
- 36-57 V
- 2-pin terminal input voltage
- 36-57 V
- Number of PSU slots
- 2
- Maximum power consumption
- 45 W
- Maximum power consumption without attachments
- 27 W
- PoE input
- 802.3bt
- PoE input voltage
- 42.5-57 V
- Cooling type
- 2 fans
- 10/100 Ethernet ports
- 1
- 25G SFP28 ports
- 8
- 100G QSFP28 ports
- 2
- Serial console port
- RJ45
- PCB temperature monitor
- Yes
- Voltage monitor
- Yes
- Certification
- CE, EAC, ROHS
- IP rating
- IP20
- Included parts
- 2 IEC cords, rack ears for CRS510, K10 screw kit, connector plug
- Switching, non-blocking Layer 2 throughput (1518/512/64-byte frames)
- 394897.1 / 385058.6 / 304838.1 Mbps
- Switching, non-blocking Layer 2 capacity (1518/512/64-byte frames)
- 789794.3 / 770117.3 / 609676.2 Mbps
- Switching, non-blocking Layer 1 throughput (1518/512/64-byte frames)
- 400100 / 400100 / 400100 Mbps
- Switching, non-blocking Layer 1 capacity (1518/512/64-byte frames)
- 800200 / 800200 / 800200 Mbps
- Routing, none (L3HW), throughput (1518/512/64-byte frames)
- 394798.1 / 384962.1 / 163140.8 Mbps
- Routing, 25 IP filter rules (Fasttrack L3HW), throughput (1518/512/64-byte frames)
- 394798.1 / 384961.9 / 157109 Mbps
- Ethernet bridging, fast path, throughput (1518/512/64-byte frames)
- 454.2 / 339.1 / 83.2 Mbps
- Ethernet bridging, 25 bridge filter rules, throughput (1518/512/64-byte frames)
- 410.5 / 195.8 / 38.7 Mbps
- Ethernet routing, fast path, throughput (1518/512/64-byte frames)
- 451.8 / 300.2 / 74.2 Mbps
- Ethernet routing, 25 simple queues, throughput (1518/512/64-byte frames)
- 442.0 / 214.6 / 27.9 Mbps
- Ethernet routing, 25 IP filter rules, throughput (1518/512/64-byte frames)
- 410.5 / 169.6 / 21.4 Mbps
- Switching test method
- Xena Networks XenaBay, RFC2544 (Xena2544); 30+ second attempts; 0.1% packet-loss tolerance
