- Product code
- CRS418-8P-8G-2S+RM
- Architecture
- ARM 64bit
- CPU
- IPQ-8072
- CPU core count
- 4
- CPU nominal frequency
- 2208 MHz
- CPU threads count
- 4
- Switch chip model
- 98DX226S
- RouterOS license
- 5
- Operating system
- RouterOS v7
- RAM size
- 1 GB
- Storage size
- 128 MB
- Storage type
- NAND
- MTBF
- Approximately 200,000 hours at 25°C
- Tested ambient temperature
- -20°C to 70°C
- AC inputs
- 2
- AC input range
- 100–240 V
- PSU slots
- 2
- Input frequency
- 50–60 Hz
- Maximum power consumption
- 215 W
- Maximum power consumption without attachments
- 28 W
- Cooling
- 4 fans
- PoE-out ports
- Ether9–Ether16
- PoE-out standard
- 802.3af/at; 24V passive PoE output
- Low-voltage PoE-out current limit
- 1.1 A
- High-voltage PoE-out current limit
- 0.56 A
- Maximum total PoE-out current
- 5.4 A
- Total PoE output current
- 5.4 A
- Total PoE output power
- 150 W
- 10/100/1000 Ethernet ports
- 17
- 1G Ethernet ports with PoE-out
- 8
- SFP+ ports
- 2
- Serial console port
- RJ45
- USB ports
- 1
- USB power reset
- Yes
- USB slot type
- USB 3.0 Type-A
- Maximum USB current
- 1 A
- CPU temperature monitor
- Yes
- Current monitor
- Yes
- PCB temperature monitor
- Yes
- Voltage monitor
- Yes
- Mode button
- Yes
- Certifications
- CE, EAC, RoHS
- IP rating
- IP20
- Included accessories
- 2x IEC cords; K-54 kit; rack ears
- Switching test equipment
- Xena Networks XenaBay; RFC2544 (Xena2544)
- Switching test maximum throughput method
- 30+ second attempts; 0.1% packet-loss tolerance; 64, 512 and 1518-byte packet sizes
- Non-blocking Layer 2 throughput
- 1518 bytes: 36,518.9 Mbps; 512 bytes: 35,609.0 Mbps; 64 bytes: 28,190.5 Mbps
- Non-blocking Layer 2 capacity
- 1518 bytes: 73,037.7 Mbps; 512 bytes: 71,218.0 Mbps; 64 bytes: 56,381.0 Mbps
- Non-blocking Layer 1 throughput
- 1518 bytes: 37,000 Mbps; 512 bytes: 37,000 Mbps; 64 bytes: 37,000 Mbps
- Non-blocking Layer 1 capacity
- 1518 bytes: 74,000 Mbps; 512 bytes: 74,000 Mbps; 64 bytes: 74,000 Mbps
- Ethernet test CPU
- IPQ-8072A
- Bridging performance, fast path
- 1518 bytes: 4,934.8 Mbps; 512 bytes: 4,655.5 Mbps; 64 bytes: 681.8 Mbps
- Bridging performance, 25 bridge filter rules
- 1518 bytes: 4,735.4 Mbps; 512 bytes: 1,652.7 Mbps; 64 bytes: 225 Mbps
- Routing performance, fast path
- 1518 bytes: 4,934.8 Mbps; 512 bytes: 3,484 Mbps; 64 bytes: 484.8 Mbps
- Routing performance, 25 simple queues
- 1518 bytes: 4,544.5 Mbps; 512 bytes: 1,593.5 Mbps; 64 bytes: 213 Mbps
- Routing performance, 25 IP filter rules
- 1518 bytes: 3,277.9 Mbps; 512 bytes: 1,136.7 Mbps; 64 bytes: 150.3 Mbps
- IPsec test CPU
- IPQ-8072A
- IPsec single tunnel, AES-128-CBC + SHA1
- 1400 bytes: 1,223 Mbps; 512 bytes: 510.4 Mbps; 64 bytes: 75 Mbps
- IPsec 256 tunnels, AES-128-CBC + SHA1
- 1400 bytes: 614.9 Mbps; 512 bytes: 242.1 Mbps; 64 bytes: 33.9 Mbps
- IPsec 256 tunnels, AES-128-CBC + SHA256
- 1400 bytes: 605.9 Mbps; 512 bytes: 239.2 Mbps; 64 bytes: 33.3 Mbps
- IPsec 256 tunnels, AES-256-CBC + SHA1
- 1400 bytes: 594.7 Mbps; 512 bytes: 234.3 Mbps; 64 bytes: 33 Mbps
- IPsec 256 tunnels, AES-256-CBC + SHA256
- 1400 bytes: 603.7 Mbps; 512 bytes: 240 Mbps; 64 bytes: 33.3 Mbps
- IPsec test maximum throughput method
- 30+ second attempts; 0.1% packet-loss tolerance; 64, 512 and 1400-byte packet sizes
