مشخصات

Brand

MikroTik

Product code

RBwAPR-2nD&R11e-LR2

Architecture

MIPSBE

CPU

QCA9531

CPU core count

1

CPU nominal frequency

650 MHz

RouterOS license

4

RAM

64 MB

Storage capacity

16 MB

Storage type

FLASH

MTBF

Approximately 200,000 hours at 25°C

Tested ambient temperature

-40°C to 60°C

DC inputs

3 (DC jack, PoE-IN, automotive)

DC jack input voltage

9–30 V

Automotive input voltage

9–30 V

PoE input

Passive PoE

PoE input voltage

9–30 V

Maximum power consumption

8 W

Cooling

Passive

Wireless band

2.4 GHz

Wireless maximum data rate

300 Mbit/s

Wireless chains

2

Wireless standards

802.11b/g/n

Wi-Fi generation

Wi-Fi 4

Wireless chip

QCA9531

2.4 GHz WLAN antenna gain

2 dBi

LoRa antenna gain

4.7 dBi

Ethernet ports

1 × 10/100 Ethernet

LoRa frequency

2.4 GHz

Mini PCI-e slots

1

SIM slots

1 × Mini SIM (modem; usable only if LoRa interface card is removed and replaced by an LTE modem)

PCB temperature monitor

Yes

Voltage monitor

Yes

Ingress protection

IP54

Certifications

CE, FCC, IC, EAC, ROHS

Included accessories

PoE injector; 24 V 0.8 A power adapter; wAP desktop stand; hose clamp; K-52 fastening set

Transmit power and receive sensitivity (2.4 GHz)

1 Mbit/s: 22 dBm / -96 dBm; 11 Mbit/s: 22 dBm / -89 dBm; 6 Mbit/s: 20 dBm / -93 dBm; 54 Mbit/s: 18 dBm / -74 dBm; MCS0: 20 dBm / -93 dBm; MCS7: 16 dBm / -71 dBm

External antenna support

Yes; manufacturer suggests TOF-2400-8V-4 Omni antenna
