مشخصات

Brand

MikroTik

Product code

E60iUGS

Architecture

ARM 32bit

CPU

EN7562CT

CPU core count

2

CPU nominal frequency

950 MHz

CPU threads count

2

Switch chip model

EN7523

RouterOS license

4

Operating system

RouterOS v7

RAM

512 MB

Storage size

128 MB

Storage type

NAND

MTBF

Approximately 100,000 hours at 25°C

Tested ambient temperature

-40°C to 70°C

DC inputs

2 (DC jack, PoE-IN)

DC jack input voltage

12–57 V

PoE-IN standard

802.3af/at

PoE-IN input voltage

18–57 V

Maximum power consumption

23 W

Maximum power consumption without attachments

5 W

Cooling

Passive

PoE-out port

Ether5

PoE-out type

Passive PoE up to 57 V

PoE-out current limit (low voltage)

0.5 A

PoE-out current limit (high voltage)

0.5 A

10/100/1000 Ethernet ports

5

1G Ethernet ports with PoE-out

1

SFP ports

1 (2.5G supported)

USB ports

1

USB slot type

USB 3.0 Type-A

Maximum USB current

1 A

USB power reset

Yes

CPU temperature monitor

Yes

PCB temperature monitor

Yes

Voltage monitor

Yes

Mode button

Yes

Certifications

CE, EAC, RoHS

IP rating

IP20

Included power adapter

24V 1.2A
